Application
Gravure / Flexo Print Inspection System for the flexible packaging industry.
Product Features
- High Speed Scanning – Newly developed LSI - FPGA (Field Programmable Gate Array).
- AI Super Resolution – Improves display images greatly.
- Carrying on compact configuration to Crossover HS.
- Outstanding Simple 2 – touch operation.
- Six inspection circuits specialized in gravure printing.
- Dual Monitor (Plus M).
- Remote Support.
- Voice Recognition.
- AI Defect Classification.
Comparison
| Model | Crossover HS 1300 | Crossover HS Coco 1200 |
| Inspection Material | Film, Paper (Aluminium is discussed separately) |
| Inspection Width | 1300 mm | 1200 mm |
| Camera | CMOS 4K full color digital sensor X2 Coco Sensor x1 |
| Inspection Speed | Max. 1000 m/min |
| Camera Resolution | 0.16mm | 0.17mm |
| Defect Image Filing | Max 130 images/sec (Blink Display, in order of size) |
| Power Consumption | 600VA (1KVA is required in consideration for transient property) |
| Ambient Temperature | 5-40 o c (install in way avoiding vibration) |
| Ambient Humidity | 20 – 80% (Without condensation) |
